Pro montáž do racku je zapotřebí zakoupit kolejnice SRTGRK1 (UPS) a SRTGRK2 (pro baterii, která je součástí dodávané UPS)


High Output Power Factor More real output power in watts. Unity on 15kVA –20kVA units.
High Efficiency “Green Mode” Achieves efficiency greater than 98%, which helps save utility and cooling costs without compromising performance or reliability.
Multi-color LCD Display Intuitive interface provides detailed and accurate information with the ability to configure locally.
Pre-installed Network Card Ability to control a group of receptacles. Ships with AP9641.
Single-Phase and 3-Phase Input/ Output Options 1PH:1PH, 3PH:1PH and 3PH:3PH power options for installation flexibility.
APC Smart-Slot Ability to add APC accessories for additional communication options.Three-year Warranty on ElectronicsAdditional year of warranty protection for electronics provides peace of mind.
Emergency Power Off (EPO) Remote UPS shutoff in the event of an emergency.
Communication Ports Serial, USB and SmartSlotfor network accessory cards.

Key Features:
Unity power factor (15kVA/15kW & 20kVA/20kW)
Up to 98% efficiency
Rack / Tower convertible
Pre-installed AP9641 NMC
7RU height (3RU Power Module + 4RU Battery Module)
Intuitive multi-colour LCD
4RU additional battery packs
Parallel capable with additional accessory
1:1, 3:1 and 3:3 phase compatible

Maximální výška 30.6cm
Maximální šířka 44.0cm
Maximální hloubka 70.0cm
Čistá hmotnost 142.5kg
Hmotnost při 157.2kg

Požadavek na jištění vstupu při zapojení 1:1 nebo 3:1 je externí jistič 100A, průřez přívodních vodičů 25 mm2
Při zapojení 3:3 externí jistič 40A, vodiče 10 mm2
