Display
Projection System DLP Single 0.65" WXGA
DMD Type DC3 DMD chip
Resolution 1280 x 800 pixels, 16:10
Brightness 3,500 Lumens
Contrast Ratio 10,000:1
Display Color 1.07 Billion Colors
Aspect Ratio Native 16:10 (5 aspect ratio selectable)
Light Source Lamp (240W)
Light Source Life* Normal 5000 hrs;Economic 8000 hrs;SmartEco 10000 hrs;LampSave 12000 hrs

Optical
Throw Ratio 0.35
Zoom Ratio Fixed
Lens F=2.5 f=5.1mm
Lens Shift Vertical: ±2%
Lens Control Manual Focus
Keystone Correction 2D, Vertical ± 15 degrees; Horizontal ± 15 degrees
Projection Offset** 122±5%( (Full-Height)
Projection Size (diagonal) 80"~100" (with wall mount)

Audio
Built-in Speaker 10W x2

Special Feature
Security Lock Security Bar, Kensington anti-theft lock slot
Feature 2D Keystone, Corner Fit, Digital zoom(2x), Digital Shrink(0.8x) and Shift, LAN Control, AMX/ PJ Link/Crestron/MDA,DMS Local Compatibility Optional Wireless Display, Optional Interactive module (PW30U/PT20) compatibility.

Connectivity
I/O Port HDMI-1 X 1
HDMI-2 X 1
PC (D-sub 15pin) X 1
Monitor out (D-sub 15pin,Female) X 1
Composite Video in (RCA) X 1
Audio in(mini jack) X 1
Audio L/R in (RCA) X 1
Audio out (mini jack) X 1
LAN Port(RJ45 for Network ) X 1
RS232 In (D-sub 9pin, male) X 1
USB TypeA (5V,1.5A) X 1
USB Type B (For service) X 1
USB Type mini B (For PointWrite module) X 1
IR Receiver(Front) X 1

Compatibility
Resolution Support VGA(640 x 480) to WUXGA_RB(1920 x 1200)
Horizontal Frequency 15~102KHz
Vertical Scan Rate 23 ~ 120 Hz
HDTV Compatibility 480i, 480p, 576i, 567p, 720p, 1080i, 1080p
Video Compatibility NTSC, PAL, SECAM

Power
Power Consumption (Max/Normal/Eco) Max 350W. Normal 320 W. Eco 260 W.
Standby Power Consumption Normal < 0.5Watts. Network < 2W.
Power Supply 100 ~ 240V AC

Dimension and Weight
Product Dimensions (WxHxD) 287.5x 206.9 x 373.3 mm
Product Weight 5 Kg+/- 100g

Operation Condition
Noise Level (Normal/Eco) 34/29 dBA
Operating Temperature 0o ~ 40o C

Accessories (Standard)
Power Cord (by region)
Remote Control (RCS011)
AAA Battery x 2
VGA cable
Warranty Card (by region)
QSG (4J.JKS01.001)
Regulatory statement x 1
Wall mount (WM04G4)

Accessories (Optional)
3D Glasses (5J.J9H25.002)
PointWrite Kit: PW30U (5A.JJR26.20E)
PointWrite Touch Module: PT20(5A.JJR26.30E)
Wireless Dongle: QCast Mirror (5A.JH328.10X)
Wireless Kit - Instashow WDC10 (9H.JF878.N4X)

OSD
On Screen Display Language Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 languages) ?
Environmental Notice
* The Contrast is measure by Full On Full Off standard.
* LightSource life results will vary depending on environmental conditions and usage. Actual product's features and specifications are subject to change without notice.
* Storage: Temperature: -20~60°C; Humidity: 10~90%RH (without condensation)
