Display
Projection System DLP
Resolution 4K UHD (3840 x 2160)
Resolution Support VGA (640 x 480) to 4K UHD (3840 x 2160)
Brightness (ANSI lumens) 2000 ANSI Lumens
Contrast Ratio (FOFO) 30,000:1
Display Color 30 Bits (1,07 billion colors)
Native Aspect Ratio Native 16:9 (6 aspect ratio selectable)
Light Source Lamp
Light Source Wattage 245W
Light Source Life Normal 4,000 hour/Economic 10,000 hours/SmartEco 15,000 hours

Optical
Throw Ratio 1.13 - 1.47 (100" @ 2.5 m)
Zoom Ratio 1.3X
Lens F/# = 1.9 - 2.47, f = 12 - 15.6 mm
Lens Shift Vertical 100%~110%
Keystone Adjustment 1D, (Auto) Vertical ± 30 degrees
Projection Offset 105%
Clear Image Size (Diagonal) 40"~200"
Image Size 30"~200"
Horizontal Frequency 15K-135KHz
Vertical Scan Rate 23-120Hz

Picture Mode Bright / Vivid TV / Cinema (Rec. 709) / D. Cinema / Silence / User 1 (HDR / HLG / ISF Night / ISF Day / 3D*)
Color Wheel Segment 6-Segment (RGBRGB)
Color Wheel Speed 2D: 96Hz ; 100Hz; 120Hz / 3D: 120Hz
Rec.709 Coverage 100%
DCI-P3 Coverage 95%

Audio
Speaker Chamber Speaker 5W x 2

Interface
HDMI x2 HDMI (2.0a/HDCP2.2)
USB Type A x1 (5V/2.5A power)
x1 ((Media Reader, FW download)
USB Type mini B x1 (FW download, service)
Audio out (3.5mm Mini Jack) x1 (mini jack)
DC 12V Trigger (3.5mm Jack) x1 (3.5mm Jack)
IR Receiver 2 (Front/Top)
RS232 x1


Special Feature
Motion Enhancer (MEMC)
ISF Night/ Day
CinemaMaster Video +
CinemaMaster Audio+2

Compatibility
HDTV Compatibility 720p 50/60Hz, 1080i 50/60Hz, 1080p 24/25/30/50/60Hz, 2160p 23/24/25/30/60Hz
3D Compatibility

Power
Power Supply VAC 100 ~ 240 (50/60Hz)
Typical Power Consumption Max 350W, Normal 340W, Eco 280W
Standby Power Consumption 0.5W Max. at 100 ~ 240VAC
Acoustic Noise (Typ./Eco.) 30/28dBA (Silence mode)
Operating Temperature 0~40 degrees (Celcius)

Dimensions and Weight
Dimensions (W x H x D)(mm) 380 x 127 x 263
Net Weight (Kg/ lbs ) 4.2 kg / 9.2 lbs

Accessories (Standard)
Carton
Remote Control w/ Battery x 1 (5J.JKC06.001)
Power Cord (by region) x 1 (3m)
User Manual CD Yes (27L)
Quick Start Guide Yes (21L)
Warranty Card (by region)
Lens cover

Accessories (Optional)
Spare Lamp Kit
3D Glasses

OSD Language
Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages)

* In 3D Mode: Resolution is 1920x1080 in 3D Mode.
** The Contrast is measured by Full On Full Off standard.
*** Lamp life results will vary depending on environmental conditions and usage. Actual product's features and specifications are subject to change without notice.
