Display
Projection System DLP
Resolution 4K UHD (3840 x 2160)
Resolution Support VGA (640 x 480) to 4K UHD (3840 x 2160)
Brightness (ANSI lumens) 1800 ANSI Lumens
Contrast Ratio (FOFO) 100,000:1 (w/ Dynamic Iris)
Display Color 30 Bits (1.07 billion colors)
Native Aspect Ratio Native 16:9 (3 aspect ratio selectable)
Light Source Lamp
Light Source Wattage 245W
Light Source Life Normal 4,000 hours /Economic 10,000 hours /SmartEco 10,000 hrs /LampSave 15,000 hrs

Optical
Throw Ratio 1.36 ~ 2.18 (100" @ 3 m)
Zoom Ratio 1.6X
Lens F/# 1.81~2.1, f 14.3(Wide) ~ 22.9(Tele)
Lens Shift Vertical: ± 60% / Horizontal: ± 23%
Keystone Adjustment 1D, Vertical ± 40 degrees
Image Size 60" ~ 200" / 300" (Clear Focus / Maximum)
Horizontal Frequency 15K-102KHz
Vertical Scan Rate 23-120Hz

Picture Mode
*** ISF Disabled: Bright / Vivid / Cinema (Rec. 709) / D. Cinema / Silence / 3D / User 1 / HDR / HLG
**** ISF Enabled: Bright / Vivid / Cinema (Rec. 709) / D. Cinema/ Silence / ISF Night / ISF Day
Color Wheel Segment 6-Segment (RGBRGB)
Color Wheel Speed 2D: 96Hz ; 100Hz ; 120Hz /3D: 100Hz, 120Hz
Rec.709 Coverage 100%
DCI-P3 Coverage 100%

Interface
HDMI x2 (HDMI 2.0b & HDCP 2.2)
USB Type A x1 (5V/2.5A power supply) x1 (USB 2.0 Media Reader/ Firmware upgrade) /x1 (USB 3.0 Media Reader/ Firmware upgrade)
USB Type mini B x1 Firmware upgrade
Audio out (3.5mm Mini Jack) x1
LAN (RJ45) x1 RJ-45 LAN input jack (10/100M)
RS232 (DB-9pin) x1 RS232 In (D-sub 9pin, male)
DC 12V Trigger (3.5mm Jack) x1 (3.5mm Jack)
IR Receiver x2 (Front/Top)
Wired Remote in (3.5mm Mini Jack) x1

Special Feature
HDR (HDR10, HLG)
Motion Enhancer (MEMC)
ISF Night/ Day
LAN control
CinemaMaster Video + (4K MotionEnh ancer, 4K Pixel Enhancer, Color Enhancer, Flesh Tone)

Compatibility
HDTV Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p

Power
Power Supply VAC 100 ~ 240 (50/60Hz)
Typical Power Consumption Max 405W, Normal 330W, Eco 247W
Standby Power Consumption 0.5W Max. at 100 ~ 240VAC
Network Stand-by Power Consumption <2W
Acoustic Noise (Typ./Eco.) 32dBA / 26dBA
Operating Temperature 0~40 degrees (Celcius)

Dimension and Weight
Dimensions (W x H x D)(mm) 492 x 168 x 349
Net Weight (Kg/ lbs ) 6.5kg / 14.3lbs

Accessories (Standard)
Remote Control w/ Battery x 1 (RCV016)
Power Cord (by region) x 1(3m)
User Manual CD (27L)
Quick Start Guide (9L)
Warranty Card (by region)
Lens cover x 1

Accessories (Optional)
Spare Lamp Kit
Ceiling mount (CMG3)
3D Glasses

OSD
OSD Language
Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages)
*** Default picture mode is Cinema (Rec. 709)

**** When ISF is enabled, default picture mode is ISF Night.
