Display
- Brightness (ANSI lumens) 3000
- Native Resolution WXGA (1280x800)
- Native Aspect Ratio 16:10
- Contrast Ratio (FOFO) 20,000:1
- Display Color 30-bit (1.07 billion colors)
- Light Source LED
- Light Source Life a. Normal 20000 hrs, b. ECO 30000 hrs
Optical
- Throw Ratio 1.55-1.7
- Zoom Ratio 1.1x
- Projection Offset (Full-Height) 100%
- Keystone Adjustment 2D, (Auto) Vertical ± 30 degrees; Horizontal ± 30 degrees
- Rec. 709 Coverage 95%
- Picture Modes 3D, Bright, Presentation, Spreadsheet, sRGB, User 1, User 2, Video
Compatibility
- Input Lag 33.4 ms (1080p@60Hz)
- Resolution Support VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
- Horizontal Frequency 15K~102KHz
- Vertical Scan Rate 23~120Hz
I/O Interface
- HDMI in
- HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4)
- USB Type A
- (x1), USB Type A-1 (2.0/Power Supply1.5A)
- RS232 in (DB-9pin) - (x1)
Audio
- Speaker (x1), 10W
Audio out (3.5mm Mini Jack) (x1)
Environment
- Operating Temperature 0~40?
Power Supply
- AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V)
- 215W
Stand-by Power Consumption
- <0.5W
Acoustic Noise (Typ./Eco.)(dB) - 34/28 dB
Accessories
- Carry Bag (Optional)
- Remote Control w/ Battery
- RCX016
- Power Cord (by region) - (Standard), x1 (1.8M)
- 3D Glasses - (Optional), DGD5
Quick Start Guide
- (x1) 21L
- Warranty Card (by region) - Yes
- Universal Ceiling Mount (Optional)
Dimension & Weight
- Dimensions (WxHxD) (mm) 303.5*107.4.*220.7
- Net Weight (kg) 2.6
- Net Weight (lb) 5.7
Projection System
- Projection System DLP
