Centralized Management Software
CC2000
ATEN's CC2000 Management Software – updated with new, powerful, features including VMware support – provides IT administrators with the tools they need to access and control their entire distributed data center environment. Offering convenient, economical, centralized management of all their IT devices, the CC2000 Management Software puts administrators in complete control of their remote data centers and branch offices no matter where in the world they are deployed.

When used in conjunction with KVM over IP switches, Serial Console Servers and Power Over the NET™ devices, the CC2000 management software allows IT administrators to remotely monitor and control all installed devices, including blade servers and virtual machines. The CC2000's Primary-Secondary architecture safeguards data transmissions through built-in redundancy factors, including automated database backup of Primary, Secondary servers and devices in addition to real-time database updating. Redundancy ensures that should any of the CC2000 servers go down, the CC2000 management system will keep functioning, since a redundant Secondary unit provides the required services until the Primary unit comes back up. This double redundancy feature, in which each Secondary server can have its own redundant Secondary server, ensures smooth management of all your devices.

The CC2000´s patented Panel DynaArray™ mode lets administrators view the output of multiple ports in individual panels on the same screen. Under this mode, the video output of each selected device displays in its own panel on the screen. To access and manage the device, simply move the mouse pointer over its panel and click.

A strong centralized management solution provides benefits in many ways:
• It lets you quickly and smoothly take control of your installation through a single portal that is accessible at any time from anywhere in the world.
• It enables a faster response to mission-critical data center emergencies.
• It eliminates the distance restrictions of traditional server room management.

Centralized Management
¦ Complete control of your enterprise - consolidates the management of ATEN devices
¦ Single portal, single sign-on, single IP address to securely access every device on the installation
¦ All devices are integrated into a single tree view for centralized access, administration, and management of a worldwide network from anywhere at anytime
¦ Primary/Secondary topology provides redundancy – including real-time database updating
¦ Double Redundancy- the CC2000 not only provides a redundant Secondary server for the Primary server, each Secondary server can also have a redundant Secondary server
¦ Aggregate Device-The KVM port, serial port and power outlet of an IT device can be associated and presented in the same web page, which enables IT administrators to completely control an IT device from a single user interface
¦ Multiplatform installation support: Windows / Linux
¦ Multiplatform client support (Windows, Mac OS X, Linux, Sun)
¦ Multi-browser support: Internet Explorer, Chrome *, Firefox, Safari, Opera, Mozilla, Netscape
* Note: The latest release of the Chrome web browser will disable the standard way in which the browser supports java plug-ins. As a result, the CC2000 will not support version 42 or future versions of the Chrome web browser. Click here for more information.
¦ Email notification of specified system events
¦ Automatic scheduling of system, configuration, and maintenance tasks
¦ Logging and auditing of system events for the CC2000 and managed devices
¦ Session logs provide serial device keystroke history
¦ ATEN/Altusen device auto-discovery with device-availability status, and alarms
¦ View, manage, and terminate active user sessions in real time
¦ User level management identification
¦ Browser-based GUI offers a multilanguage interface to minimize user training time and increase productivity
¦ Generic Device support - users can be redirected to 3rd party data center devices from the CC2000
¦ Flexible logging and reporting options
¦ Blade Server Integration Supports Centralized Server Control, Power Management - to power on/off the server, Sensor and log Readings for Service Processor Management
¦ APC PDU (AP79xx, AP89xx, AP86xx) support
¦ Supports single sign-on for Dell DRAC 5, iDRAC 6, IBM RSA II, HP iLO 2, iLO 3, iLO 4, Dell CMC, IBM AMM, and HP OA
¦ Integrates all access right – Web, SSH/Telnet, VNC/RDP, IPMI/SPM, KVM, serial, power to target device
¦ VMware Virtual Infrastructure includes Center Servers, ESX Servers, Virtual Machines and Citrix XenServer
¦ Panel DynaArray™ view the output of multiple ports in individual panels on the same screen
¦ Power association with ATEN/Altusen PDU enables the switch's KVM ports to associate with the PDU's power outlets for remote power management of the servers from the switch's interface
¦ Web-based wizard to quickly install devices
¦ Primary can pull device port names from Secondary servers. Primary can push device port names to Secondary server
¦ Advanced search function for log entries
¦ Strong session management/Integrates multi-session (ATEN iKVM, Blade server, VMware, PDU, and so on)
¦ License Saving-use Aggregate Devices to consolidate multiple ports into a single node license
¦ Data export /import to remote server or local in real time or on schedule. AES/DES encryption support for data export
¦ OOBC, PAP and CHAP authentication
¦ IPv6 support
¦ NTS support- allow your device to get the accurate time from a server that the administrator assigns
¦ Supports SNMP Manager V1, V2c & V3

¦ Powerful Security
¦ Powerful security features include both internal and external authentication - external authentication support includes LDAP, LDAPS, Kerberos, Active Directory, RADIUS, TACACS+, and NT Domain
¦ Option to force users of all CC managed devices to be authenticated through the CC - users cannot log in to the devices directly
¦ Compliant with the X.509 Digital Certificate Standard
¦ Supports TLS 1.2 data encryption and RSA 1024-bit certificates to secure users log in from browser
¦ Flexible session time-outs
¦ Configurable user and group permissions for server access and control
¦ Supports strong password protection, SAS 70 compliance for configurable amount of failed login attempts and user ID lock out parameters
¦ Devices can identify themselves by Name, MAC address, or IP in the browser
¦ IP and MAC filtering
¦ Private CA support
¦ Supports OTP (One-Time Password) authentication Click here for further information regarding OTP function NEW!

Package Contents
1x CC2000 USB License Key
1x Software CD
1x User Instructions
CCS1 (Add-on 1 Secondary Server License)
