Enclosure Color Black

Active Area (mm)
8.54" x 5.34" / 136mm x 217mm

Resolution
1280 x 800 @ 60Hz

Operating Temperature
0°C to 40°C / 32°F to 104°F

Storage Temperature
-20°C to 50°C / -4°F to 122°F

Number of Touches
Multi Touch (Up to 10)

Contrast Ratio
800:1

Response Time-total (typical)
25 msec

Brightness (typical)
LCD Panel: 400 nits
TouchPro PCAP: 344 nits

Number of Colors
10-bit (1.07 billion)

Input Video Format
No

Power Supply
No

Input Voltage
No

Power Consumption (Typical)
No

Humidity
Operating: 20% to 80%

Storage: 5% to 95%
Operating: 20% to 80%
Storage: 5% to 95%
MTBF
50,000 hours demonstrated

Other Features
No

Diagonal Size
10.1'' diagonal, Active matrix TFT LCD (LED)


I/O Ports
Micro HDMI output
Micro SD slot
Ethernet 1x LAN (Gigabit)
GPIO

Dimensions
10.06" x 7.13" x 0.99" / 255.41mm x 181.11mm x 25.1mm
1x USB 3.0 support, 4x microUSB

Memory (RAM)
3GB DDR3L

Processor
Qualcomm® Snapdragon™ APQ8053 2.0GHz Octa-Core Processor

Storage
32GB SSD

Power Consumption (Typical)
ON: 10.2W
OFF: 0.4W
SLEEP: 5.0W

Power Supply
AC input voltage: 100-240 VAC
Input frequency: 50-60 Hz

power adapter (included in accessory box)
