Remote server management is provided through industry-standard interfaces:
•Intelligent Platform Management Interface (IPMI) Version 2.0
•Simple Network Management Protocol (SNMP) Version 3 (no SET commands; no SNMP v1)
•Common Information Model (CIM-XML)
•Representational State Transfer (REST) support
•Redfish support (DMTF compliant)
•Web browser - HTML 5-based browser interface (Java and ActiveX not required) using a responsive design (content optimized for device being used - laptop, tablet, phone) with NLS support

There are two XClarity Controller upgrades available for the server, Advanced and Enterprise.

Lenovo XClarity Controller Advanced adds the following remote control functions:
•Remotely viewing video with graphics resolutions up to 1600x1200 at 75 Hz with up to 23 bits per pixel, regardless of the system state
•Remotely accessing the server using the keyboard and mouse from a remote client
•Capturing blue-screen errors
•International keyboard mapping support
•LDAP-based authentication

Lenovo XClarity Controller Enterprise enables the following additional features:
•Boot Capture
•Remote mounting of CD-ROM (ISO) and diskette (IMG) files as virtual drives
•Virtual console collaboration
•Power capping
•License for XClarity Energy Manager




LenovoPress - https://lenovopress.com/lp0648-thinksystem-st550-server#systems-management
