SPECIFICATIONS

Camera
Resolution: H.264/MJ: @30FPS
(1)3840×2160 (2)2560×1440
(3)1920×1080 (4)1280×720
(5)1024×576 (6)960×540
(7)800×600 (8)640×480
(9)640×360 (10)480×270
(11)352×288 (12)320×240
NV12 / YUY2: @30FPS
(1)1920×1080(2)1280×720
(3)640×360
Sensor: IMX577 1/2.3 inch, CMOS, 12M pixel
FOV: 117.8° (DFOV) ,109° (HFOV),74.4° (VFOV)
PTZ: EPTZ (5X digital Zoom)
Digital Noise Reduction: Yes
White Balance: Yes
Exposure: Yes
Audio
Microphone array: 6 element, 8 meters pickup range
Speaker: treble module x1, mid-bass modulex1 in one box
(Maximum output 8W)
Output Power: 80 dBA @ 1000 Hz @ 1 meter at maximum volume
I/O
USB-TypeC: 1
Audio Out: 1
DC 2.0 Power: 1
RJ45: 1 (Only for power supply)
IEEE 802.3 at,25.50W (max)
Power Button: Power Button: In startup mode, press the power button to mute.
In standby mode, press the power button to power on.
MIC Mute Button: Yes
USB feature
Connection type: USB 3.0, downward compatible with USB2.0
Video Compression: MJPEG /YUY2 / H.264 / NV12
USB audio: 16K sampling rate, support UAC2.0
USB video communication protocol: UVC 1.1
UVC PTZ control: Support (Control Via Remote controller)
Intelligent Function
Auto Framing: Yes
Voice tracking: Yes
System Compatibility
OS: Windows 7 /8.1/10/11 or higher
macOS® 10.10 or higher
Google ChromebookTM Version 29.0.1547.70 or higher
Android
Accessory (inbox)
USB Type-C cable: 1.8m typeC x1
(include TypeC to A Plug adaptor)
Remote Control: Yes
Power adapter: 1
Wall mount components: 1
Screws: Yes
Lens Cover: 1
QSG: Yes
Compliance statement: Yes
